Programming tests and monitoring results can be controlled through our powerful Labtest software, which allows complete and accurate data management in accordance with European, North American and International Standards. Labtest allows full control of processing, filing, managing, and transmitting data to the company network, database, and performs many other functions.
This Quasar frame has a flexible and modular construction. It can be equipped with various grips and fixtures, as well as extensometers, additional load cells, temperature chambers and many accessories, for a wide range of applications (tensile, compression, flexure, etc.).
|Capacity of frame and max allowed load||2,000 kN (449,618 lbf)|
|Load cell nominal size
(tensile & compression)
|Standards met or exceeded||ISO 7500-1, ASTM E4, EN 10002-2, JIS B7721, GB/T 16825.1, DIN 51221, BS 1610 and other equivalent|
|Testing area depth||Unlimited|
|Power Rating||11,000 W|
|Machine weight (without accessories)||10,500 Kg (23,150 lb)|
|Finishing||Silver RAL 9006 / Black RAL 9011|
|PC interface||Ethercat (A dedicated Ethernet port on PC is required)|
< 72 db
3,910 mm (153,94 in.)
2,054 mm (80.87 in.)
|Depth||1,575 mm (62.00 in.)|
